13700,00 ₾
They draw off dangerous gases safely and quickly. The housing made of a robust ABS carbon plastic passes voltage into the floor and thus prevents static charges and for this reason dangerous sparking. The housing and motor sealing is in keeping with the high protection class IP55 and offers an effective protection against dust and water. Anti-static hoses ensure safe operation.
A practical hose canister with anti-static hose is available for ComPact 1500 EX.
Special features in explosion-proof areas: Installation conditions and different hazardous areas have to be observed. Connect device to explosion-proof power socket only. Earth anti-static hoses, when required.
ATEX: motor/housing: II 2G EEx de IIB T6 / II 2 G EEx d IIB
| Article No. | 1110827 |
| Air flow rate max.(cum/h) of each stage | 1,195 |
| Compression (Pa) | 195 |
| Electric Connection (V/z) | 230 / 50 |
| Power consumption max.(kW) | 0.25 |
| Current consumption (A) | 1.2 |
| Length / Width / Height (mm) | 330 / 305 / 355 |
| Weight (kg) | 8.2 |
| Volume (dB(A)) | 74 |
| Protection class (IP) | 55 |
| Hose (diam. in mm) | 205 |
| Hose length max. (m) | 15 |
